性能參數 |
掃描模式 | Area Image |
對比度 | 20% minimum reflectance difference |
光源 | Aiming Pattern : 630nm LED 、Illumination ：630nm LED |
識讀精度 | SR Model、4 mil Code 39 、7milDM 、HD Model 、3 mil Code 39 、5milDM |
條碼靈敏度 | Roll: 360 ?; Pitch: ± 75 ?; Skew: ± 65 ? |
移動條碼讀取能力 | Up to 25 inch/63.5 cm per second |
讀取距離 | SR Model 5 mil (0.13mm) C39 13 mil (0.33mm) UPC/EAN 10 mil (0.25mm) DMHD Model3 mil (0.07mm) C39 5 mil (0.13mm) C3913 mil (0.33mm) UPC/EAN 5 mil (0.13mm) DM10 mil (0.25mm) QR 5.7-16.7(2.24"-6.57") 4.7-39.7(1.85"-15.63") 4.7-17.2(1.85"-6.77") 4.7-9.7(1.85"-3.82") 4.7-12.7(1.85"-5.0") 4.2-18.2(1.65"-7.17") 5.2-10.7(2.05"-4.21") 5.2-9.7(2.05"-3.82") |
操作模式 | Trigger, Alternative, Level, Force, Presentation |
數據接口 | RS232 serialUSB HID (USB Keyboard) USB COM port emulation |
人機界面 | 3 LEDs for power, Status, OK/NG indications Test button Programmable beeper |
機器設定及 | Bar code command, Serial command Windows utility - FuzzyScan PowerTool |
資料編輯 | Condensed DataWizard via bar code command Full-feature DataWizard via FuzzyScan PowerTool DataWizard Premium via FuzzyScan PowerTool |
圖像采集 | Graphic Format : BMP |
識讀碼制 |
一維條碼 | Code 39, Code 39 Full ASCII, Code 32, Code 128, GS1-128, Codabar, Code 11, Code 93,Standard & Industrial 2 of 5, Interleaved & Matrix 2 of 5, IATA, UPC/EAN/JAN, UPC/EAN/JAN with Addendum, Telepen, MSI/Plessey & UK/Plessey , GS1 DataBar, Linear & Linear Stacked |
二維條碼 | PDF417, Micro PDF417, Codablock F, Code 16K, Code 49, Composite Codes, DataMatrix, MaxiCode, QR Code, Aztec, MicroQR |
郵政碼 | Australian Post, US Planet, US Postnet, Japan Post Dutch KIX code, Intelligent Mail, British Post |
外觀特征及電子特征 |
外部尺寸 | 47.6 mm (L) x 40.6 mm (W) x 25.6 mm (H) |
重量 | 101g |
窗口選擇 | Choice of front-view or side-view model |
數據接口 | 9-pin D-sub female (RS232 version) USB 4-pin Type A (USB version)15-pin D-sub HD female (Universal version) |
輸入電壓 | 5VDC ± 10% |
工作電流 | Operating : Typical 285 mA @5VDC Standby : Typical 160 mA @5VDC |
環境參數 |
跌落規格 | Withstand 1.5m/5ft. drop to concrete |
IP等級 | IP54 |
